AI技术提升六面体网格生成自动化问题

发布时间:2024-01-03

技术背景

1. 业务场景:在使用工业软件对各物理场问题分析过程中,相对于其他网格,六面体网格具有更好的计算精度、更高的计算效率、更强的抗畸变能力并能更自然地顺应边界和物理场的走向。目前,六面体网格主要依赖半自动半手工模式--扫掠法来得到。

2. 技术选题的关键性:六面体剖分以扫掠法为主,对一些复杂的工程问题,所需工作量要以人月甚至人年记。如能提升六面体网格生成自动化程度,将大幅减轻工程师的劳动强度,显著提升工作效率,缩短仿真时间和产品开发周期。

3. 技术选题的泛用性:六面体网格生成技术是工业软件和一些相关领域的通用技术,并不局限于某个特定的应用场景。

技术挑战

1. 设计基于AI的三维几何体分块算法,将物体分割为一些适合于扫掠的块。

2. 对于分割后剩余的不可扫掠块,设计AI指导下的空腔填充算法,以填充剩余块内部。

3. 空腔填充算法也应适用于四面体网格。

技术诉求

1. 可自动剖分模型的复杂程度:用基本体素进行10次以内布尔运算得出的几何模型(占比30%)。

2. 对更复杂模型可减少交互工作量30%以上。

3. 单元质量要求:雅可比值不低于0.1。

参考文献

[1] Pietroni N, Campen M, Sheffer A, et al. Hex-mesh generation and processing: a survey[J]. ACM TOG , 2022,42(2): 1-44.

[2] Fang X, Xu W, Bao H, and Huang J. All-Hex Meshing using Closed-Form Induced Polycube. ACM TOG , 2016; 35(4).

[3] Tautges TJ, Blacker T, Mitchell SA. The whisker weaving algorithm: A connectivity-based method for constructing all-hexahedral finite element meshes. IJNME, 1996; 39(19): 3327–3349.

[4] Price MA, Armstrong CG. Hexahedral mesh generation by medial surface subdivision: part II. Solids with flat and concave edges. IJNME, 1997; 40: 111-136.

[5] Livesu M, Pietroni N, Puppo E, Sheffer A, and Cignoni P. LoopyCuts: practical feature-preserving block decomposition for strongly hexdominant meshing. ACM TOG(SIGGRAPH) ; 2020: 39(4).

[6] Lu Y, Gadh R, Tautges TJ. Feature based hex meshing methodology: feature recognition and volume decomposition. Computer Aided Design, 2001; 33(3): 221–32.

[7] Lei, Na , et al. "Quadrilateral mesh generation II: Meromorphic quartic differentials and Abel-Jacobi condition." Computer Methods in Applied Mechanics and Engineering , 2020.

[8] Liu JF, Sun SL, Chen YQ. A new method of quality improvement for quadrilateral mesh based on small polygon reconnection, Acta Mechanica Sinica , 2012, 28(1):140-145.

[9] Biesbroeck A V , Shang F , Bassir D . CAD Model Segmentation Via Deep Learning[J]. International Journal of Computational Methods, 2020.

联系人:吴瑾    lion.wujin@huawei.com
